Quick Details

  • Application: Laser Engraving
  • Condition: New
  • Laser Type: CO2
  • Engraving Area: 400*600mm
  • Engraving Speed: 0-30000mm/min
  • CNC or Not: Yes
  • Cooling Mode: Water Cooling
  • Applicable Material: Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood
  • Graphic Format Supported: AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: ChinaCNCzone
  • Model Number: 50W CO2 3D Mini Laser Engraving Machine Price Competitive
  • Dimension(L*W*H): 1020*700*600mm
  • Certification: CE, None
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Total power: <300W
  • Laser power: 50W
  • Laser type: CO2
  • Working area: 400*600 mm
  • Engraving depth: 0-10 mm
  • Cutting depth: 0-5 mm
  • Engraving speed: 0-30000 mm/min
  • Cutting speed: 0-360 mm/min
  • Lifting platform: 0-300 mm, Honeycomb Screen
  • Min shaping character: Character: 2*2mm, Letter: 1*1mm

Packaging & Delivery

Packaging Details: Paypal, E-Credit line, Escrow
Delivery Detail: 1-7 Days after payment comfirmed



50W CO2 3D Laser Engraving Machine Price Good for Wood, Acrylic, Leather, PCB, Jeans, Silicons, Glass, Stone



Product Description

High lights for this Widely Used 50W CO2 Laser Cutting Machine



1. Adjustable Speed and Power, Smooth and Precise Engraving and Cutting

2. USB Interface

3. Air Assist, Remove heat and combustible gases from the cutting surface.

    18W Air pump, flow can be 38L/Min.

4. Embedded Exhaust Fan, Easier intall, Safer transport.

    40W  exhaust fan, flow can be  5.27m³\Min.

5. Rotary Axis, Engrave any cylindrical object.

6. Cellular platform, Leave no chippings on working area.

7. Intuitive Control Panel, Set Speed, power and more controls directly from the laser.

8. Water Cooling and Protection System.

    15W Water Pump, flow can be  7.5L/H.

9. Lsser position.

10. Emergency Stop Button.

11. Larger Size, 400*600mm working area.

12. Lifting platform is electric control.

13. Drag - and - chain transmission line

15. A limit swith let it can only work when the cover is closed.
16. Machine service life: 1000-1500H for laser tube, 3-5 years for machine body.





Applied Material of this Widely Used 50W CO2 Laser Cutting Machine





Technical detailes for this Widely Used 50W CO2 Laser Cutting Machine

Total power<300W
Laser power50W
Laser typeCO2
Power supplyAC 220V/110V
Working area400*600 mm
Engraving depth0-10 mm
Cutting depth0-5 mm
Engraving speed0-600mm/s
Cutting speed0-600 mm/s
Lifting platform0-300 mm  Honeycomb Screen
Locating precision<0.01 mm
Min shaping characterCharacter: 2*2mm, Letter: 1*1mm
Working temperature5℃-45℃
Working humidity5%-95%
Resolution ratio≤2000dpi
Data transfer interfaceUSB 2.0
System environmentWindows XP / Win 7 / Win 8
Cooling Water Cooling and protection system
Graphic Format SupportedThe Files which CorelDraw & WinsealXP can identify
(BMP,JPEG,PLT,CDR,AI,) TIFF,PCX,DIB,TIF
Compatible softwareCorelDraw,WinsealXP
Color separationNO
Sloping engravingNO
Cuts off the water supply the protectionYes
Outside Dimensions1020*700*600 mm
Net Weight75KG
PackingWooden box
Package Dimension1200*940*870 mm
Package Weight195 kg





Main structure of this Widely Used 50W CO2 Laser Cutting Machine













More details of this Widely Used 50W CO2 Laser Cutting Machine

















































Packaging & Shipping

 Packing

Packing Material: Wooden box

Package Dimension:  1200*940*870 mm

Package Weight: 195 kg

 Shipping

Ship out in 1-3 day after payment comfirmed.

We also have store in our US, UK, GER, AUS warehouse.

If ship from China, too heavy, can only ship by sea, delivery will be 40-60days.





FAQ

MOQ

1 set. A sample welcomed, you may want more after a nice try.

Warranty

1 year free for spare parts, life time  maintenance service.

User Manual

We provide English user manual for free

Software

A software CD will send with the machine.

Interface

USB Interface

Graphic Format Supported

The files which CorelDraw can identify,  BMP,JPEG,PLT,CDR ....
